American Lighting

ADAPTIVE PRO 200W Power Supply

ADAPTIVE PRO 200W Power Supply

Regular price $289.55 USD
Regular price Sale price $289.55 USD
Sale Sold out

The Adaptive Pro 5-in-1 dimmable drivers are designed to operate with any standard MLV / ELV / Incandescent TRIAC (forward phase) dimmer switch or can also be used with secondary side controls systems. Encased in a sealed low profile aluminum enclosure Suitable for outdoor locations.

  • 24V DC Constant voltage 200W hardwire LED driver
  • 5-in-1 Forward and Reverse Phase Dimming:
    ELV / MLV / TRIAC / 0-10V / 1-10V / 10V PWM / Potentiometer
  • Class I metal housing (Type HL)
  • 8” (SJTW) Lead & Tail Wire
  • Short circuit, over-load, and over temperature protections
  • Class P / Type HL / FCC Compliant
  • cULus Listed - Wet location rated
SERIES: ADPTPRO-200W
INPUT VOLTAGE: 100-277V AC
OUTPUT VOLTAGE: 24V DC
MAX LOAD: 200W
MINIUMUM LOAD: 20W (Dimming)
DIMMABLE: MLV / ELV / TRIAC / 0-10V / 1-10V / 10V PWM
OPERATING TEMP: -40°F to 140°F (-40°C to 60°C)
DIMENSIONS: 10.07”L x 3.07”W x 1.85”H
RATING: cULus Listed (Wet Location)
